Axial Fan Zhiel-Abeeg FC050-VDS.4F.V7

Article number : 171608
Type : FC050-VDS.4F.V7
Designation : Axial fan with diecast blades
Rated values : 3~400V ±10% D/Y 50Hz P1 0.55/0.39kW 1.05/0.68A 1380/1040/min COSY 0,78 test
Electrical connection : Terminal box K62
ErP Data : Efficiency ηstatA: 37.6 %
Efficiency grade:  Nactual = 45.6 / Ntarget = 40* *ErP 2015
Type of protection : IP54
Thermal class : THCL155
Mounting type terminal box : Mounted on Stator
Min. operating temperature : -40°C***
Connection diagram : 1360-108XA
Rating plate : 1x fixed
Fitting position : H/Vu/Vo
Motor protection : thermal contact
Impregnation : Moisture and hot climate protection
Condensation : Condensation water holes in stator/rotor open
Quality of bearings : ball bearing with long-time lubrication
Material Rotor : Aluminium
Painting rotor : Rotor 1 coat paint resistance class 1 (L-TI-0596)
colour rotor : RAL 7030 (stone grey)
painting stator : Stator 1 coat paint resistance class 1 (L-TI-0596)
colour stator : RAL 7030 (stone grey)
Material blades : Aluminium
Painting impeller : Impeller 1 coat paint resistance class 1 (L-TI-0596)
Colour blades : RAL 7030 (stone grey)
Painting mot.suspens : Motor suspension 1 coat paint resistance class 1 (L-TI-0596)
colour suspension : RAL 7030 (stone grey)
Weight : 9,40
